DISCOVER THE ADVANTAGES OF ALUMINIUM SYSTEM WINDOWS AND DOORS
The world is changing rapidly and new demands are born everyday. Modern buildings require the design and construction of fenestration systems with high standards. By focusing always on the specifications and the requirements of the most advanced markets worldwide, we have created a product portfolio which incorporates innovative products and responds perfectly to the modern building needs. The needs of our customers are quite wide, and so is our product portfolio. Each of our products was designed with one think in mind: How to offer the best possible solution and maximize the value for our customers.
Windows & Doors and Curtain Walls
We have ideal Windows & Doors and Curtain wall systems for your home – our wide product range with Multiple Hinged, Sliding or Bi Folding, Sound Proof, Burglar Proof, Anti Ballistic System Windows & Doors, Curtain wall & Curtain wall unitized system incorporates all the expertise of our innovative Research & Development department and is characterised by top aesthetics and excellent functionality. Aiming always for top quality, Our’s energy efficient aluminium windows and doors are the first choice for new constructions and renovation projects in which compromise is not an option. Offering the ideal blend of unmatched aesthetics and advanced functionality, our aluminium system windows and doors are capable of taking the oomph factor of any space to the ultimate level. They are manufactured and designed with precision to meet the unique requirements of every customer.
FEATURES AND BENEFITS
- Durable – Resistant to corrosion and the elements
- Low-Maintenance – Do not fade or discolour, easy to clean
- Eco-friendly 100% recyclable and reusable
- Energy-Efficient Technology that offers great insulation.
- Slim and lightweight while maintaining inherent strength of the material
- Myriads of design options available
SLIDE & FOLD DOORS
SMARTIA I M9800
SMARTIA M9800 is a slide and fold door system with top-hung operation and suitable for normal and large constructions. It offers sturdy and elegant solutions applied to middle-end projects, such as modern residences, office buildings, conference centres, hotels, restaurants and many other.
- Easy machining and installation
- High performance in terms of wind resistance, air permeablity and water tightness
- Sturdy structure with flawless and long-lasting operation
TECHNICAL CHARACTERISTICS
| Visible aluminium face width | 143 mm sash-sash |
| Frame height | 33 mm |
| Frame width | 57.5 mm |
| Sash height | 44.8 |
| Sash width | 50 mm |
| Sash weight | 125 kg/sash |
| Glazing | 24-32 mm |
SLIDING WINDOWS & DOORS
COMFORT I M 900
The smallest and lightest sliding windows and doors system, ideal solution for conventional constructions
SLIDING SYSTEM
M 900 is the lightest sliding system for highly cost efficient constructions. Ideal proposal for low-cost solutions without compromising in quality.
- Supports single or double glazing up to 20 mm thickness.
- Recommended for small to medium size spans
- Cooperates perfectly with the system M900 for Tilt & Turn typologies.
TECHNICAL CHARACTERISTICS
| Visible aluminium face width | 88 mm |
| Frame height | 37.4/62.5 mm |
| Frame width | 45/54.5 mm |
| Sash height | 61 |
| Sash width | 28 mm |
| Interlocking profile width | 65.5 mm |
| Sash weight | up to 80 Kg |
| Glazing | up to 20 mm |
SLIDING WINDOWS & DOORS
SMARTIA I M1 4600
Our sliding system windows and doors of fine design, offers high performance ideal for warmer climates M1 4600 is a brand new sliding system with extremely elegant straight lines, incorporating all the expertise. It meets the modern architectural trends and the requirements for especially high performance and is the ideal solution for sliding systems in areas with warmer climates.
- Maximum visibility and natural light with only 23 mm width at the interlocking profile
- Exceptional wind load resistance performance, certified under extreme conditions
- Easy access, with low threshold. Ideal for multi-track constructions.
- Vast range of typologies, compatible with various mechanisms
- Smooth and easy gliding, thanks to inox rails.
TECHNICAL CHARACTERISTICS
| Visible aluminium face width | 95.5 mm |
| Frame height | 31.5 / 40 mm |
| Frame width | 41 / 92 / 143 / 205 / 256 mm |
| Sash height | 67 mm/79 mm |
| Sash width | 35 mm |
| Interlocking profile width | 23 / 68.5 mm / 78.5 mm |
| Sash weight | 120 kg |
| Glazing | up to 24mm |
SLIDING WINDOWS & DOORS – CONCEALED
The new ingenious sliding system for minimal sliding frames, which maximize natural light. Its unique design is completely in line with the latest architectural trends.
M1 2500 is the new ingenious minimal sliding system for modern sliding frames. Its impressive minimal lines incorporate the latest trends in architectural design. It was specially designed for warmer climates and can cover a considerable range of construction needs
- Meeting stile width of just 72mm with integrated ergonomic handle
- Vast range of typologies compatible with various mechanisms
- Max. IGU thickness up to 32mm and weight per sash up to 120Kg
- Smooth and easy sliding thanks to inox rails
TECHNICAL CHARACTERISTICS
| Visible aluminium face width | Concealed profiles |
| Frame height | 30.5/62 mm |
| Frame width | 137/155 mm |
| Sash height | 30/76 mm |
| Sash width | 45 mm |
| Interlocking profile width | 32 mm |
| key | value |
| Sash weight | vup to 180 Kg Up to 250 Kg concealed version |
| Glazing | 4 up to 32 mm |
SLIDING & LIFTING SYSTEM
SMARTIA I M 45000
SMARTIA M 45000 is the system for sliding & lifting windows and doors with modern flat design. The system meets a wide range of needs using common profiles for the construction of simple sliding and lifting sliding typologies. Ideal solution for large spans and warmer climates.
- Only 32 mm visible aluminium face width at the interlocking profile available for sliding typologies
- Easy use even for heavy sashes up to 300 Kg with the lifting sliding mechanism
- Smooth gliding thanks to inox rails of the system
- Extra reinforcement profiles for higher and sturdier constructions.
- Exceptional performance certified by ift Rosenheim.
TECHNICAL CHARACTERISTICS
| Visible aluminium face width | 106 mm sliding/110,5 mm lift & slide |
| Frame height | 40 mm |
| Frame width | 113.5 mm |
| Sash height | 45 mm |
| Interlocking profile width | 32/78.5 mm sliding 83 mm lift & slide |
| Sash weight | upto 189 Kg sliding, up to 300 Kg lift & slide |
| Glazing | up to 30 mm |
CASEMENT WINDOWS & DOORS
COMFORT I M 940
Low-cost hinged windows and doors system which is one of the smallest and lightest products with good performance and construction benefits
HINGED SYSTEM
M 940 is a cost efficient and lightweight system for a without compromising on performances. Available in a variety of construction solutions.
- Water and air tightness is achieved through 3 levels of EPDM gaskets
- Great diversity of designs for windows and doors.
- Can be used in multiple typologies with narrow spans and cost efficient projects
- The system is compatible with European Groove mechanism. Can be combined with the sliding system COMFORT M900
TECHNICAL CHARACTERISTICS
| Visible aluminium face width | 74.7 mm |
| Frame height | 58.6 mm |
| Frame width | 37/42 mm |
| Sash height | 56 mm |
| Sash Width | value |
| Sash weight | up to 80 Kg |
| Glazing | from 10 up to 24 mm |
CASEMENT WINDOWS & DOORS
SMARTIA I M1 5000
A high-aesthetically hinged windows & doors system which covers any construction need and provides a great level of security
- Basic system depth 50mm.
- Robust & flexible system that can support all potential typologies of hinged windows, doors and pivot windows
- Available special profiles for main entrances, smoke proof doors and panic doors.
- The system also supports “block window” constructions (concealed sash)
- Various designs (e.g. flat, curved, classic)
- Either European groove or PVC groove hardware can be applied.
TECHNICAL CHARACTERISTICS
| Visible aluminium face width | 137 mm |
| Frame height | 48 mm |
| Frame width | 50 mm |
| Sash height | 66 mm |
| Sash Width | 59 mm |
| Sash weight | up to 180 Kg |
| Glazing | up to 47 mm |
CURTAIN WALL SYSTEM
SMARTIA I M6
SMARTIA M6 is a complete system for curtain walls, which is ideal for sturdy constructions and can meet effectively all architectural requirements, as for example the creation of large frames.
- 55 mm width of mullions and transoms.
- Large variety of mullions for high wind loads
- Various covers for external surfaces of high aesthetic value
- Structural version available without visible aluminium covers
- Various hinged window types can be applied: parallel projected, top hung, inwards tilt & turn, concealed sash tilt & turn, seamless inwards tilt & turn all Tilt & Turn SMARTIA systems.
- Constructions with inclined or polygonal surfaces.
- Can be combined with all types of doors of the SMARTIA series
TECHNICAL CHARACTERISTICS
| Exterior visible width | 55 mm |
| Mullion depth | 65/223 mm |
| Transom depth | 30/179 mm |
| Glazing | Stick type with EPDM gaskets |
| Glass thickness | Up to 50 mm |
| Outer frame max inertia | I x =2082 Iy =183 cm4 |
| Mullions max inertia | I x =32 Iy =105 cm4 |
| Transform max inertia | I x =568 Iy =64 cm4 |
CURTAIN WALL SYSTEM
SMARTIA I M7 SMARTIA M7 is a complete system for high energy efficiency curtain walls, which offers quality constructions in affordable prices and fully meets all stability and safety requirements
- 50 mm width of mullions and transoms
- Option of structural curtain wall constructions without aluminium covers, using the same mullions and transoms
- Option of structural curtain wall constructions without aluminium covers, using the same mullions and transoms
- Low fabrication cost due to accessories and ease of fabrication
- Includes an effective water evacuation system.
- Special supports for shading blades.
- Various hinged window types can be applied: parallel projected, top hung, inwards tilt & turn, concealed sash tilt & turn, seamless inwards tilt & turn, all Tilt & Turn SMARTIA systems
- Constructions with inclined or polygonal surfaces
- Can be combined with all types of doors of the SMARTIA series.
EXTERIOR AESTHETICS
With horizontal and vertical cover (standard). Structural (glass only)
TECHNICAL CHARACTERISTICS
| Exterior visible width | 50 mm |
| Mullion depth | 28-267 mm |
| Transom depth | 16.5-266 mm |
| Glazing | Stick type with EPDM gaskets |
| Glass thickness | Up to 50 mm |
| Mullions max inertia | I x =2788 Iy =131,20 cm4 |
| Transform max inertia | I x =973 Iy =60,3 cm4 |
CURTAIN WALL SYSTEM
SMARTIA I M65 SMARTIA M65 is a unitized curtain wall system ideal for highrise buildings, which provides freedom in architectural design. The construction of the building’s envelope is done by assembling big panels consisted of many glass frames, either structural or with visible aluminium covers. Every unit can be freely designed by the architect, whilst the system guarantees easy and secure application.
- 65 mm basic system width
- Easy replacement of broken glasses
- Various hinged window types can be applied: parallel projected, top hung, all Tilt & Turn windows of SMARTIA systems
- Certified system performance by the IFT Rosenheim & AAMA institutes
EXTERIOR AESTHETICS
Visible aluminium frame: 28.5 mm Distance between frames: 8 mm
TECHNICAL CHARACTERISTICS
| Exterior visible width | 78 mm |
| Mullion depth | 160 mm |
| Transom depth | 160 mm |
| Mullions max inertia | I x =643 cm4 Iy =46 cm4 |
| Transform max inertia | I x =161 cm4 Iy =568 cm4 |
| Max dimensions WxH | 1500×3500 cm |
CURTAIN WALL UNITIZED SYSTEM
SMARTIA I M78 SMARTIA M78 is a cost efficient unitized curtain wall, which combines minimal aestethics with structural robustness. Its Structural Silicone Glazing construction offers maximum transparency at the external surface of the façade. Modular units, including glazing panes, are prefabricated in workshop conditions and this results in a fast and economic installation with minimum manpower and tooling requirements. This construction mode, renders M78 an ideal system for high rise buildings, where meeting demanding deadlines is a prerequisite.
- Basic system width 78mm
- Structurally bonded glazing, providing a flush exterior appearance
- Various hinged typologies can be implemented: projected, parallel projected and all and turn windows.
- Horizontal unit joint 12mm
- Vertical unit joint 19mm
- Stack joint height 92mm
- 3 levels of sealing
- Glazing from 32 mm up to 46mm
TECHNICAL CHARACTERISTICS
| Exterior visible width | 78 mm |
| Mullion depth | 160 mm |
| Transom depth | 160 mm |
| Mullions max inertia | I x =643 cm4 Iy =46 cm4 |
| Transform max inertia | I x =161 cm4 Iy =568 cm4 |
| Max dimensions WxH | 1500×3500 cm |
